Memory seat circuit for Buick LaCrosse II facelift (2013-2016)

BLK WIRE BLK/BLU WIRE BLU/GRN WIRE BLU/VIO WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE DOWN DOWN FWD DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT LUMBAR SUPPORT PUMP DRIVER SEAT MEMORY SWITCH GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRY/BLK WIRE GRY/GRN WIRE MEM MEM SEAT SW SET SIG MEM SW LOW REF MEM SEAT SW SIG (1) RED/YEL WIRE RIGHT REAR HAPTIC SEAT MTR CTRL LEFT REAR HAPTIC SEAT MTR CTRL RWD RWD UP USED) VERTICAL MTR POS SNSR SIG RECLINE MTR POS SNSR SIG VIO WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/WHT WIRE

1 2 BATTERY POSITIVE VOLTAGE BATTERY POSITIVE VOLTAGE B+ FWD BLK WIRE BLU/VIO WIRE BLU/YEL WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT FRONT VERTICAL MOTOR (UNDER RIGHT FRONT CORNER OF DRIVER SEAT) DRIVER SEAT HORIZONTAL MOTOR (UNDER DRIVER'S SEAT) DRIVER SEAT LUMBAR SUPPORT VALVE ASSEMBLY DRIVER SEAT REAR VERTICAL MOTOR (UNDER RIGHT REAR CORNER OF DRIVER SEAT) DRIVER SEAT RECLINE MOTOR (LOWER RIGHT SIDE OF DRIVER SEAT BACK) DRVR/SEAT CIRCUIT BREAKER FRONT VERTICAL MTR DWN CTRL FRONT VERTICAL MTR UP CTRL GRN WIRE GRN/BRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/GRN WIRE HORIZONTAL MTR FORWARD CTRL HORIZONTAL MTR REARWARD CTRL HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT SIDE OF DASH) LINEAR INTERCONNECT NETWORK BUS 8 LOGIC LOW SPEED GMLAN SERIAL DATA 1 2 3 4 5 6 MEM ST FUSE REAR VERTICAL MTR DOWN CTRL REAR VERTICAL MTR UP CTRL RECLINE MTR FORWARD CTRL RECLINE MTR REARWARD CTRL RED/GRN WIRE RED/YEL WIRE RWD DN UP SEAT MEMORY CONTROL MODULE (UNDER DRIVER'S SEAT) UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY) WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/WHT WIRE
