Buick LaCrosse II facelift (2013-2016) Headlamps circuit, without high intensity discharge

1 2 312 712 RH HDLP LO BEAM SPLY V LH HDLP LO BEAM SPLY V 16 11 22 HDLP SW ON SIG 23 18 10 DRL RELAY CTRL HDLP HI BEAM RLY CTRL FOG LAMP RLY CTRL 23 24 HI SPD GMLAN SER DATA (-) HI SPD GMLAN SER DATA (+) AMBIENT LIGHT SENS SIG AMBIENT LIGHT/ SUNLOAD SENSOR (CENTER OF DASH) BLK WIRE BLU/BRN WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE FOG LAMP FUSE FRONT FOG LAMP FTP FUSE GRN WIRE GROUND GRY WIRE GRY/BLU WIRE HDLP DIMMER SW HI BEAM SIG HDLP OFF SIG CTRL HDLP SW PARK LP SIG HDLP SW FLASH TO PASS SIG HEADLAMP HIGH BEAM RELAY HEADLAMP LOW BEAM RELAY HI BEAM HI BEAM RT HID HVAC CONTROL MODULE LEFT DAYTIME RUNNING LAMP, LEFT HEADLAMP ASSEMBLY LEFT HIGH BEAM SOLENOID ACTUATOR LEFT LOW BEAM HEADLAMP LH FUSE RH FUSE FUSE LIGHTING CTRL SW REF LIGHTING CTRL SW SIG LOW REF LT HID RED WIRE RED/BLK WIRE RELAY RIGHT HEADLAMP ASSEMBLY RIGHT HIGH BEAM SOLENOID ACTUATOR RIGHT DAYTIME RUNNING LAMP RIGHT LOW BEAM HEADLAMP TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY) VIO WIRE WHT WIRE WHT/BRN WIRE WINDSHIELD WIPER MOTOR YEL WIRE

2500 2501 1134 7684 COMPUTER DATA LINES SYSTEM BATTERY FUSE BLOCK (TOP OF BATTERY) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/VIO WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DIMMER SWITCH DRIVER INFORMATION CENTER DISPLAY FOG LAMP SWITCH FRONT FOG LAMP IND FUSE GRN WIRE GROUND GRY WIRE GRY/RED WIRE HEAD PARK AUTO HEADLAMP SWITCH HIGH BEAM LAMP IND HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED IGN INSTRUMENT CLUSTER LEFT FRONT FOG LAMP LOGIC LOW SPD GMLAN SER DATA LT GRN WIRE MIL IGN OFF PARK BRAKE CONTROL SWITCH PARK BRK APPLY SW SIG PARK BRK RELEASE SW SIG PARK BRK RELEASE SW VOL REF PARK BRK SW SPLY VOLT PARKING BRAKE CONTROL MODULE (BEHIND LEFT REAR WHEEL LINER) RED WIRE RIGHT FRONT FOG LAMP UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY) VIO WIRE VIO/GRY WIRE WHT WIRE WHT/BRN WIRE YEL WIRE YEL/RED WIRE
