Buick LaCrosse II facelift (2013-2016) trans- mission output Wiring diagram
This page shows the only wiring diagram for the component.trans- mission output, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trans- mission output (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 BATTERY SOL CTRL
1 2 3 4 5 6 DATA (-) DATA (-) DATA (+) DATA (+) VOLT GND
2.4L 3.6L
9 8 17 DATA + DATA - SPLY VOLT
ANTI-LOCK BRAKES SYSTEM
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BRN/GRN WIRE
BRN/LT GRN WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DK BLU WIRE
DRIVER INFORMATION CENTER DISPLAY
ELECTRONIC BRAKE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
IGN
INSTRUMENT CLUSTER
LOGIC
POWER STEERING CONTROL MODULE (LOWER LEFT SIDE OF DASH)
RED WIRE
RED/DK BLU WIRE
SERIAL DATA (-) SERIAL DATA (+)
SHAFT SPEED SENSOR
SOL LO REF
STEERING ANGLE SENSOR (BASE OF STEERING COLUMN)
SYSTEM
TRANS- MISSION OUTPUT
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
W/ ADAPTIVE CRUISE CONTROL
WHT WIRE
WHT/DK BLU WIRE
Go to component -> Electronic power steering circuit, with variable effort -> TRANS- MISSION OUTPUT
