Buick LaCrosse II facelift (2013-2016) serial data - serial data + whl spd sens sig rf whl spd sens low rf Wiring diagram
This page shows the only wiring diagram for the component.serial data - serial data + whl spd sens sig rf whl spd sens low rf, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram serial data - serial data + whl spd sens sig rf whl spd sens low rf (1 of 1)
12 VOLTAGE BRAKE FLUD LVL SENS SIG BRK VACUUM SW SIG SERIAL DATA- SERIAL DATA +
5 VOLT REF
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE BOOSTER PUMP MOTOR RELAY (RIGHT SIDE OF ENGINE COMPT)
BRAKE FLUID LEVEL SWITCH (LEFT KICK (ON BRAKE FLUID PANEL) RESERVOIR)
BRAKE PRESSURE MODULATOR
BRAKE VACUUM SENS SIG WHL SPD SENS SIG LF LF WHL SPD SENS LOW REF
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC BRAKE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
FUSE
FUSE 26
FUSE 41
GRN/BRN WIRE
GRN/GRY WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT STEERING KNUCKLE ASSEMBLY)
LEFT REAR WHEEL SPEED SENSOR (LEFT REAR UPPER CONTROL ARM)
LOW REFERENCE BATTERY +
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT WHEEL SPEED SENSOR
SENS SIG RIGHT REAR LOW REF RIGHT REAR SERIAL DATA + SERIAL DATA -
SERIAL DATA - SERIAL DATA + WHL SPD SENS SIG RF WHL SPD SENS LOW RF
SERIAL DATA ENABLE WHL SPD SENS SIG LR WHL SPD SENS LOW REF LR
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VIO WIRE
W/ CONTINUOUSLY VARIABLE REAL TIME DAMPING CHASSIS
W/O CONTINUOUSLY VARIABLE REAL TIME DAMPING CHASSIS
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> SERIAL DATA - SERIAL DATA + WHL SPD SENS SIG RF WHL SPD SENS LOW RF
