Buick LaCrosse II facelift (2013-2016) power right backup lamp wiring diagram
This page shows the only wiring diagram for the component.power right backup lamp, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
power right backup lamp wiring diagram (1 of 1)
AUDIO/ VIDEO MEDIA INPUT DISC ADAPTER PLAYER
AUXILIARY AUDIO INPUT
BLK WIRE
ELECTRONIC BRAKE CONTROL MODULE
HUMAN MACHINE INTERFACE CONTROL MODULE
INFO DISPLAY MODULE
LEFT COOLING FAN MOTOR
POWER RIGHT BACKUP LAMP
POWER STEERING CONTROL LOGIC
POWER STEERING CONTROL MODULE
RADIO
RIGHT REAR TURN SIGNAL LAMP
RIGHT REAR WINDOW DEFOGGER NOISE FILTER
RIGHT TAIL LAMP ASSEMBLY
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
W/ ACTIVE FRONT GRILL SHUTTER
W/ BELT DRIVE POWER STEERING
W/ ON STAR
W/ RSE W/O RSE
W/O ACTIVE FRONT GRILL SHUTTER
W/O BELT DRIVE POWER STEERING
Go to component -> Ground distribution circuit (7 of 7) -> POWER RIGHT BACKUP LAMP
