Buick LaCrosse II facelift (2013-2016) passenger left rear window window switch motor wiring diagram
This page shows the only wiring diagram for the component.passenger left rear window window switch motor, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
passenger left rear window window switch motor wiring diagram (1 of 1)
2.4L
3.6L
ABS PUMP FUSE
ABS WDO FRT VALVE FUSE FUSE
AFL MTR FUSE
AMPLIFIER FUSE
AUDIO AMPLIFIER (IF EQUIPPED)
AUXILIARY HEATER COOLANT PUMP RELAY
BATT RVC FUSE BCM 6 FUSE
BATTERY
BATTERY FUSE BLOCK (TOP OF BATTERY)
BODY CONTROL MODULE
BPIM BATT VES FUSE
BRAKE BOOSTER PUMP MOTOR RELAY
BRK VAC PUMP FUSE
BRN WIRE
CANN VENT FUSE
CHASSIS CONTROL MODULE
CONTROL SOLENOID VALVE ASSEMBLY AUTOMATIC TRANSMISSION ASSEMBLY
ECM BATT FUSE
ELECTRONIC BRAKE CONTROL MODULE
ELECTRONIC DRIVER BRAKE WINDOW CONTROL MOTOR MODULE
ENGINE CONTROL MODULE
EPB FUSE
EVAPORATIVE EMISSION VENT SOLENOID VALVE
FRONT SEAT HEATING CONTROL MODULE
FSCM FUSE
FUEL PUMP DRIVER CONTROL MODULE
FUSE
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
GENERATOR
GRN WIRE
GRY WIRE
HEADLAMP CONTROL MODULE (IF EQUIPPED)
HTD ST DR FUSE
KEYLESS ENTRY CONTROL MODULE
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP HORIZONTAL MOTOR
MEM ST FUSE
MGU CLT PMP FUSE
PARKING BRAKE CONTROL MODULE
PASSENGER LEFT REAR WINDOW WINDOW SWITCH MOTOR
PEPS FUSE
POWER STEERING CONTROL MODULE (W/ BELT DRIVE)
POWER STEERING CONTROL MODULE (W/ VARIABLE EFFORT)
POWER STEERING CONTROL MODULE (W/O VARIABLE EFFORT OR BELT DRIVE)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEADLAMP ASSEMBLY
RIGHT HEADLAMP HORIZONTAL MOTOR
RIGHT REAR WINDOW SWITCH
SEAT MEMORY CONTROL MODULE
STARTER FUSE
STARTER MOTOR
STARTER RELAY
STARTER/GENERATOR CONTROL MODULE HYBRID/EV BATTERY PACK
SUNROOF CONTROL MODULE (IF EQUIPPED)
SUNROOF FUSE
SUNROOF SUNSHADE MOTOR MODULE (IF EQUIPPED)
TCM BATT FUSE
TO IGNITION MAIN RELAY (DIAGRAM 2 OF 5) AFL BATT FUSE
TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 2 OF 5)
TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 3 OF 5)
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VIO RED/ WIRE
W/ FRONT ACTIVE GRILLE SHUTTERS W/O FRONT ACTIVE GRILLE SHUTTERS
W/ PASSIVE KEYLESS ENTRY
W/ POWER W/O POWER STEERING STEERING CONTROL CONTROL
WDO RR FUSE
Go to component -> Power distribution circuit (1 of 5) -> PASSENGER LEFT REAR WINDOW WINDOW SWITCH MOTOR
