Buick LaCrosse II facelift (2013-2016) overhead console accent lamp Wiring diagram
This page shows the only wiring diagram for the component.overhead console accent lamp, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram overhead console accent lamp (1 of 1)
2 1 LR DOOR AJAR SW SIG NETWORK BUS 4
6 5 RR DOOR AJAR SW SIG NETWORK BUS 4
AJAR SW SIG
BLK WIRE
BRN WIRE
CENTER CONSOLE CUPHOLDER ACCENT LAMP
COMPUTER DATA LINES SYSTEM
DRIVER DOOR HANDLE FLOOD LAMP
DRIVER DOOR LATCH ASSEMBLY
DRIVER DOOR PULL HANDLE FLOOD LAMP
GRN/YEL WIRE
GROUND DISTRIBUTION
GRY WIRE
HANDLE FLOOD LAMP
LEFT INSTRUMENT PANEL ACCENT LAMP
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR DOOR PULL HANDLE LAMP
LEFT REAR WINDOW SWITCH
LEFT TAILLAMP ASSEMBLY
LT GRN/GRY WIRE
LT GRN/YEL WIRE
NCA WIRE
NETWORK BUS 3
OVERHEAD CONSOLE ACCENT LAMP
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER DOOR)
PASSENGER LEFT REAR DOOR DOOR PULL HANDLE FLOOD LAMP HANDLE FLOOD LAMP
RED WIRE
RIGHT INSTRUMENT PANEL ACCENT LAMP
RIGHT REAR DOOR HANDLE FLOOD LAMP RIGHT REAR DOOR PULL HANDLE LAMP
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR WINDOW SWITCH
SYSTEM
W/ CUSTOM INTERIOR PACKAGE LAMP
WHT WIRE
WHT/YEL WIRE
YEL/ WHT WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> OVERHEAD CONSOLE ACCENT LAMP
