Buick LaCrosse II facelift (2013-2016) oss oss high low wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 GND HI SPD GMLAN SER DATA (+) AUTOMATIC TRANSMISSION ASSEMBLY BCM 1 FUSE BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CONTROL SOLENOID DK BLU WIRE DRIVER INFORMATION CENTER (DIC) ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) GMLAN SERIAL DATA BUS + GRN WIRE GRY WIRE GRY/VIO WIRE HDLP SW HDLPS OFF SIG CTRL HI SPD GMLAN SER DATA (-) IGN VOLT HI SPD GMLAN SER DATA (-) WAKEUP SER DATA HI SPD GMLAN SER DATA - HOT AT ALL TIMES HOT AT ALL TIMES UNDERHOOD FUSE BLOCK TCM BATT (LEFT SIDE FUSE OF BATTERY) HOT W/ IGNITION MAIN RELAY ENERGIZED IGN INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT SIDE OF DASH) ISS ISS HIGH LOW LOGIC GMLAN LOW REF OSS OSS HIGH LOW P/N PARK/ NEUTRAL SIG GMLAN SERIAL DATA BUS- PC 1 SOLENOID PC 2 SOLENOID PC 3 SOLENOID PC 4 SOLENOID PC 5 SOLENOID POWER DISTRIBUTION SYSTEM PRESSURE CONTROL (PC) SOLENOID VALVE 1 PRESSURE CONTROL (PC) SOLENOID VALVE 2 PRESSURE CONTROL (PC) SOLENOID VALVE 3 PRESSURE CONTROL (PC) SOLENOID VALVE 4 PRESSURE CONTROL (PC) SOLENOID VALVE 5 RAP RELAY COIL CTRL RAP RLY COIL CTRL RED WIRE RED/DK GRN WIRE RED/WHT WIRE SHIFT SOLENOID (SS) VALVE 1 SHIFT SOLENOID (SS) VALVE 2 SS 1 SS 2 TCC SOLENOID TFP 1 TFP 3 TFP 4 TFP 5 TFT TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID VALVE TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION FLUID PRESSURE SWITCH TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION INPUT SHAFT SPEED SENSOR (ISS) TRANSMISSION INTERNAL MODE SWITCH (IMS) TRANSMISSION MANUAL SHIFT SWITCH TRANSMISSION OUTPUT SHAFT SPEED SENSOR (OSS) TRANSMISSION SHIFT LEVER TRN FSC IGN FUSE TRNS RANGE SIG A TRNS TRNS TRNS GND RANGE RANGE RANGE SIG C SIG B SIG P VALVE ASSEMBLY VIO WIRE VIO/BLK WIRE VIO/YEL WIRE WHT WIRE WHT/GRY WIRE YEL WIRE
