Buick LaCrosse II facelift (2013-2016) linear interconn network bus 12 Wiring diagram
This page shows the only wiring diagram for the component.linear interconn network bus 12, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram linear interconn network bus 12 (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/LT GRN WIRE
DISPLY FUSE
GROUND
HEAD-UP DISPLAY
HEAD-UP DISPLAY SWITCH
HEADLAMP ON
HOT AT ALL TIMES
HUD
HUD SW LOW REF
HUD SW SIG
INFO
INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT SIDE OF DASH)
LINEAR INTERCONN NETWORK BUS 12
LOGIC INSTRUMENT CLUSTER
LT GRN/BLK WIRE
NCA WIRE
RED/LT BLU WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Head-up display circuit -> LINEAR INTERCONN NETWORK BUS 12
