Buick LaCrosse II facelift (2013-2016) left headlamp multifunction led control module Wiring diagrams
This page contains all the electrical diagrams for the component. left headlamp multifunction led control module, in which he is found in the car Buick LaCrosse II facelift (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left headlamp multifunction led control module (1 of 2)
ASSEMBLY
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER OUTSIDE REARVIEW MIRROR LAMP LEFT TURN SIGNAL REPEATER LAMP
GMLAN LO SPD
GRN WIRE
GRN/VIO WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/ VIO WIRE
GRY/BRN WIRE
INSTRUMENT CLUSTER
LEFT FRONT PARK LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP MULTIFUNCTION LED CONTROL MODULE
LEFT PARK DAYTIME RUNNING LAMP
LEFT TURN IND
LOGIC
MIRROR
MIRROR LAMP
PARK LAMP IND
PASSENGER OUTSIDE REARVIEW
PNK WIRE
RIGHT TURN IND
RIGHT TURN SIGNAL REPEATER LAMP
RUN/CRANK IGNITION 1 VOLT
SER DATA
VIO WIRE
VIO/GRY WIRE
W/ HID
W/O HID
WHT WIRE
WHT/ BLK WIRE
WHT/ BLU WIRE
WHT/YEL WIRE
Go to component -> Exterior lamps circuit (2 of 3) -> LEFT HEADLAMP MULTIFUNCTION LED CONTROL MODULE
Wiring diagram left headlamp multifunction led control module (2 of 2)
1 2 33 32 RF DRL SPLY VOLT LF DRL SPLY VOLT
2 3 2540 2140 B+ B+
22 10 5060 278 DATA LINES LOW SPD GMLAN SER DATA SYSTEM AMBIENT LIGHT SENS SIG
22 11 16 13 306 103 HDLP SW PARK LP SIG
AMBIENT LIGHT/ SUNLOAD SENSOR (CENTER OF DASH)
BCM 4 BCM 1 FUSE FUSE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER
CRUISE CONTROL, SOUND SYSTEMS
FOG LAMP FUSE
FRONT FOG
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/BLU WIRE
HDLP DIMMER SW HI BEAM SIG
HDLP OFF SIG CTRL HDLP SW ON SIG
HDLP SW FLASH TO PASS SIG
HEADLAMP HIGH BEAM RELAY
HEADLAMP LOW BEAM RELAY
HEADLAMPS LEVELING CIRCUIT
HIGH LOW FTP
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY FUSE BLOCK FUSE (TOP OF BATTERY)
HVAC CONTROL MODULE
INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT SIDE OF DASH)
LAMP RELAY
LED CONTROL MODULE
LEFT HEADLAMP ASSEMBLY
LEFT HEADLAMP BALLAST
LEFT HEADLAMP MULTIFUNCTION LED CONTROL MODULE
LEFT HIGH BEAM SOLENOID ACTUATOR
LEFT LOW BEAM HEADLAMP
LEFT PARK/DAYTIME RUNNING LAMP
LIGHTING CTRL SW REF
LIGHTING CTRL SW SIG
LOW REF
LT HI BEAM FUSE RT HI BEAM FUSE RT HID FUSE
LT HID FUSE
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RIGHT HEADLAMP ASSEMBLY
RIGHT HEADLAMP BALLAST
RIGHT HEADLAMP MULTIFUNCTION
RIGHT HIGH BEAM SOLENOID ACTUATOR
RIGHT LOW BEAM HEADLAMP
RIGHT PARK/DAYTIME RUNNING LAMP
TO WINDSHIELD WIPER MOTOR)
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VIO BRN/ WIRE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit, with high intensity discharge (1 of 2) -> LEFT HEADLAMP MULTIFUNCTION LED CONTROL MODULE
