Buick LaCrosse II facelift (2013-2016) down air outlet switch Wiring diagram
This page shows the only wiring diagram for the component.down air outlet switch, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram down air outlet switch (1 of 1)
A/C ON IND
A/C ON SWITCH
AMBIENT AIR TEMPERATURE SENSOR (LEFT FRONT OF VEHICLE
AMBIENT LIGHT/ SUNLOAD SENSOR (CENTER OF DASH)
ANTI-THEFT SYSTEM HEADLIGHTS SYSTEM
BATT POS
BLK WIRE
BLK/DK BLU WIRE
BLU WIRE
BRN/LT GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DATA
DEFROST SWITCH
DISPLAY DISPLAY
DK BLU BLK/ WIRE
DK BLU/GRY WIRE
DOWN AIR OUTLET IND
DOWN AIR OUTLET SWITCH
DRIVER INFORMATION CENTER DISPLAY
ENGINE COOLANT TEMPERATURE GAUGE
ENGINE COOLANT TEMPERATURE IND
FAN DOWN SWITCH
FAN UP SWITCH
GMLAN
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HVAC CONTROLS
INSTRUMENT CLUSTER
LEFT COOLING FAN MOTOR
LOGIC
LOW REF
LOW SPD
LT GRN WIRE
LT GRN/VIO WIRE
ON BUMPER FASCIA)
RECIRCULATION IND
RECIRCULATION SWITCH
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RIGHT COOLING FAN MOTOR
SENS SIG
SERIAL
UP AIR OUTLET IND
UP AIR OUTLET SWITCH
UPPER AIR OUTLET IND
UPPER AIR OUTLET SWITCH
VOLT
W/ ONSTAR W/O ONSTAR
WHT/BLU WIRE
WINDSHIELD
WINDSHIELD DEFROST IND
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 4) -> DOWN AIR OUTLET SWITCH
