Buick LaCrosse II facelift (2013-2016) distance sensing cruise control module Wiring diagram
This page shows the only wiring diagram for the component.distance sensing cruise control module, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram distance sensing cruise control module (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE BOOSTER PUMP MOTOR RELAY
BRN WIRE
COOLING
DISTANCE SENSING CRUISE CONTROL MODULE
FAN SPEED CONTROL RELAY
GRY WIRE
HORN ASSEMBLY
IGNITION MAIN RELAY
LEFT DAYTIME RUNNING LAMP,
LEFT FRONT HOOD FOG AJAR LAMP SWITCH
LEFT FRONT PARK LAMP (IF EQUIPPED) ACTIVE GRILL AIR SHUTTER ACTUATOR
LEFT FRONT SIDE LEFT HEADLAMP MARKER BALLAST LAMP
LEFT HEADLAMP HORIZONTAL MOTOR
LEFT LEFT COOLING COOLING FAN FAN DIODE DIODE
LOW SPEED COOLING FAN DIODE
RIGHT DAYTIME RUNNING LAMP
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT HEADLAMP BALLAST
RIGHT HEADLAMP HORIZONTAL MOTOR
RIGHT HEADLAMP MULTI-FUNCTION LED CONTROL MODULE
RIGHT HIGH BEAM SOLENOID ACTUATOR
RIGHT LOW BEAM HEADLAMP
RIGHT RIGHT FRONT FRONT SIDE TURN MARKER SIGNAL LAMP LAMP
W/ ADAPTIVE CRUISE CONTROL
W/ HID
W/O HID
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER PUMP
WINDSHIELD WASHER PUMP RELAY
Go to component -> Ground distribution circuit (1 of 7) -> DISTANCE SENSING CRUISE CONTROL MODULE
