Buick LaCrosse II facelift (2013-2016) dim sig led ambient lighting ctrl Wiring diagram
This page shows the only wiring diagram for the component.dim sig led ambient lighting ctrl, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dim sig led ambient lighting ctrl (1 of 1)
3 4 BATT POS VOLT BATT POS VOLT
4 17 5 BATT POS VOLT IND DIM CTRL HAZ LED
7 13 TRUNK LP CTRL INADVERTENT PWR CTRL
BCM 7 BCM 2 FUSE BLOCK FUSE FUSE (LOWER LEFT SIDE OF DASH)
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
CENTER CONSOLE COMPARTMENT LAMP
CENTER CONSOLE COMPARTMENT LAMP SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL, SOUND SYSTEMS
DIM SIG LED AMBIENT LIGHTING CTRL
DIMMER SWITCH
DRIVER DOOR COURTESY
FOG LAMP SWITCH
FUSE 32
GRN/GRY WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/GRN WIRE
GRY/LT GRN WIRE
HEADLAMP SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL
INSTRUMENT PANEL COMPARTMENT LAMP
INTR LP CTRL
INTR LP DEFEAT SW SIG COURTESY LP SW SIG PUDDLE LAMP SUPLY VOLT 19 8
LAMP
LEFT REAR DOOR COURTESY
LEFT SUNSHADE
LEFT SUNSHADE MIRROR LAMP
LEFT TAILLAMP ASSEMBLY
LIFT GATE AJAR SW SIG
LIGHTING CTRL SW SIG LIGHTING CTRL SW REF
LT GRN/GRY WIRE
LT GRN/YEL WIRE
NCA WIRE
NETWORK BUS 3
NETWORK BUS 4
PASSENGER DOOR COURTESY
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID LATCH (IN TRUNK LID)
RED/BRN WIRE
RED/DK GRN WIRE
RED/WHT WIRE
RIGHT REAR DOOR COURTESY
RIGHT SUNSHADE
RIGHT SUNSHADE MIRROR LAMP
UNDER HOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
W/ CUSTOM INTERIOR PACKAGE LAMP
WHT WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 3) -> DIM SIG LED AMBIENT LIGHTING CTRL
