Buick LaCrosse II facelift (2013-2016) computer data lines system 6107 6108 Wiring diagram
This page shows the only wiring diagram for the component.computer data lines system 6107 6108, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer data lines system 6107 6108 (1 of 1)
APPLY SW SIG RELEASE SW SIG
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM 6107 6108
DRIVER INFORMATION CENTER DISPLAY
EPB FUSE
GRN WIRE
GRY WIRE
GRY/RED WIRE
HI SPD GMLAN - HI SPD GMLAN - HI SPD GMLAN - SUPPLY VOLTAGE SERIAL DATA
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LOGIC
LOW SPD GMLAN
PARK BRAKE CONTROL SWITCH (ON PARK BRAKE ASSEMBLY)
PARK IND
PARKING BRAKE CONTROL MODULE (BEHIND LEFT REAR WHEEL LINER)
RED WIRE
RED/VIO WIRE
SERIAL DATA
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Park brake system circuit -> COMPUTER DATA LINES SYSTEM 6107 6108
