Buick LaCrosse II facelift (2013-2016) (bumper harness, 200 mm from breakout to right middle rear object Wiring diagram
This page shows the only wiring diagram for the component.(bumper harness, 200 mm from breakout to right middle rear object, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (bumper harness, 200 mm from breakout to right middle rear object (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP
DOME LAMP SWITCH
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
INTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
LEFT FRONT DOME/ READING LAMPS
LEFT LICENSE PLATE LAMP
LEFT SUNSHADE
LEFT SUNSHADE MIRROR LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TAILLAMP ASSEMBLY
LOGIC
PARK BRAKE CONTROL MODULE
PASSENGER AIR BAG DISABLED INDICATOR
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID LATCH
REAR DOME/ READING LAMP
RIGHT BACKUP LAMP
RIGHT FRONT DOME/ READING LAMPS
RIGHT LICENSE PLATE LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT SUNSHADE
RIGHT SUNSHADE MIRROR LAMP
SENSOR
VIO/WHT WIRE
W/ REMOTE W/O REMOTE KEYLESS KEYLESS ENTRY ENTRY
Go to component -> Ground distribution circuit (5 of 7) -> (BUMPER HARNESS, 200 MM FROM BREAKOUT TO RIGHT MIDDLE REAR OBJECT
