Buick LaCrosse II facelift (2013-2016) 14 3 4 most ctrl most ser data - most ser data + Wiring diagram

14 3 4 MOST CTRL MOST SER DATA - MOST SER DATA + 21 18 17 NETWORK BUS 12 MOST SER DATA - MOST SER DATA + 3 8 5 LO SPD GMLAN SER DATA NETWORK BUS 5 NETWORK BUS 10 5 6 MOST SER DATA - MOST SER DATA + AUDIO AMPLIFIER (RIGHT SIDE OF TRUNK) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/VIO WIRE HEAD-UP DISPLAY (IF EQUIPPED) INFO DISPLAY MODULE LINEAR INTERCONNECT NETWORK BUS 12 LINEAR INTERCONNECT NETWORK BUS 3 LO SPD GMLAN SER DATA LOGIC DRIVER WINDOW MOTOR LOGIC DRIVER WINDOW SWITCH LOGIC INSTRUMENT CLUSTER LOGIC PASSENGER WINDOW MOTOR MEDIA DISC PLAYER MOST CTRL MOST SER DATA (+) NETWORK BUS 10 RADIO RED/WHT WIRE RIGHT STEERING WHEEL CONTROLS SWITCH STEERING WHEEL AIR BAG COIL W/ PREMIUM AUDIO SPEAKER SYSTEM W/ REAR SEAT ENTERTAINMENT W/O PREMIUM AUDIO SPEAKER SYSTEM W/O REAR SEAT ENTERTAINMENT WHT/GRN WIRE WHT/VIO WIRE
