Buick LaCrosse II facelift (2013-2016) 1 2 3 4 5 6 7 8 9 10 temp sig 5 temp sig 4 temp sig 2 temp sig 1 Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 7 8 9 10 temp sig 5 temp sig 4 temp sig 2 temp sig 1, which is found in the car Buick LaCrosse II facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 7 8 9 10 temp sig 5 temp sig 4 temp sig 2 temp sig 1 (1 of 1)
1 2 3 4 5 6 7 8 9 10 TEMP SIG 5 TEMP SIG 4 TEMP SIG 2 TEMP SIG 1
1 2 3 4 5 6 7 8 9 10 TEMP SIG 7 TEMP SIG 3
BATTERY ENERGY CONTROL MODULE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN/GRN WIRE
FROM MAIN CONNECTOR (DIAGRAM 2 OF 4)
FROM MANUAL SERVICE DISCONNECT (DIAGRAM 4 OF 4)
GRN WIRE
GRY WIRE
HYBRID/EV BATTERY PACK (RIGHT SIDE OF LUGGAGE COMPT)
HYBRID/EV BATTERY SECTION 1
HYBRID/EV BATTERY TEMPERATURE SENSOR 3
HYBRID/EV BATTERY TEMPERATURE SENSOR 4
HYBRID/EV BATTERY TEMPERATURE SENSOR 5
INLET HYBRID/EV BATTERY PACK AIR TEMPERAT- URE SENSOR 2
LOW REF
LOW REF LOW REF
LOW REF LOW REF LOW REF LOW REF
ORG/ WIRE
ORG/GRY WIRE
RED WIRE
STARTER/GENERATOR COOLANT PUMP (INSIDE ENGINE COMPT)
TEMP SIG 6
VIO/WHT WIRE
VOLTAGE ROUTED FROM CELL 1 (+)
WHT WIRE
WHT/ORG WIRE
