Buick LaCrosse II (2009-2013) steering wheel heater control module Wiring diagram
This page shows the only wiring diagram for the component.steering wheel heater control module, which is found in the car Buick LaCrosse II (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel heater control module (1 of 1)
ACCESSORY DC/AC POWER INVERTER MODULE
BLK WIRE
BREAKOUT TO ELECTRONIC BRAKE CONTROL MODULE)
CENTER CONSOLE 1 ACCESSORY POWER RECEPTACLE
CENTER CONSOLE 2 ACCESSORY POWER RECEPTACLE
CENTER CONSOLE COMPARTMENT LAMP
DATA LINK CONNECTOR
ELECTRONIC BRAKE CONTROL MODULE
FUEL PUMP CONTROL MODULE
HORN SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT PANEL COMPARTMENT LAMP
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 1
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 2
LEFT CENTER CONSOLE ARMREST ACCENT LAMP
LEFT CENTER CONSOLE CUP HOLDER ACCENT LAMP
LEFT INSTRUMENT PANEL ACCENT LAMP
LEFT INSTRUMENT PANEL COURTESY LAMP
LEFT STEERING WHEEL CONTROLS SWITCH
NCA WIRE
PARK BRAKE CONTROL SWITCH
PARK POSITION SWITCH
PASSENGER INSTRUMENT PANEL AIR BAG
PNK WIRE
RIGHT CENTER CONSOLE ARMREST ACCENT LAMP
RIGHT CENTER CONSOLE CUP HOLDER ACCENT LAMP
RIGHT COOLING FAN MOTOR
RIGHT INSTRUMENT PANEL ACCENT LAMP
RIGHT INSTRUMENT PANEL COURTESY LAMP
RIGHT LOWER INSTRUMENT PANEL ACCENT LAMP
RIGHT REAR RIGHT REAR SIDE MARKER TURN SIGNAL LAMP LAMP
RIGHT REAR WINDOW DEFOGGER NOISE FILTER
RIGHT STEERING WHEEL CONTROLS SWITCH
RIGHT TAIL LAMP
RIGHT TAIL/ RIGHT STOP, TURN BACKUP SIGNAL LAMP LAMP
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATER
STEERING WHEEL HEATER CONTROL MODULE
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
W/ HEATED STEERING WHEEL SWITCH
Go to component -> Ground distribution circuit (3 of 4) -> STEERING WHEEL HEATER CONTROL MODULE
