Buick LaCrosse II (2009-2013) starter relay ctrl Wiring diagram
This page shows the only wiring diagram for the component.starter relay ctrl, which is found in the car Buick LaCrosse II (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram starter relay ctrl (1 of 1)
AUTOMATIC TRANSMISSION ASSEMBLY
AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH
BATTERY (LEFT SIDE OF ENGINE)
BATTERY FUSE BLOCK (TOP OF BATTERY) FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
EXCEPT 2.4L 2.4L
FUSE
GMLAN SERIAL DATA
GRN WIRE
GROUND
GRY WIRE
IGN VOLT
IGNITION SWITCH
LOCK
PARK/NEUTRAL SIG (1)
RED WIRE
RUN WIRE
SERIAL DATA
STARTER MOTOR
STARTER RELAY
STARTER RELAY CTRL
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VALVE ASSEMBLY
VIO/GRY WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
Go to component -> Starting circuit -> STARTER RELAY CTRL
