Buick LaCrosse II (2009-2013) light ctrl sw ref Wiring diagram
This page shows the only wiring diagram for the component.light ctrl sw ref, which is found in the car Buick LaCrosse II (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light ctrl sw ref (1 of 1)
22 1 SERIAL DATA BATT POS VOLT
AIR BAG COIL
AUTO
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL, SOUND SYSTEMS
DIMMER SWITCH
DOME/ READING LAMPS
FOG LAMP SWITCH
FRONT DOME/ READING LAMPS
FUSE
GARAGE DOOR OPENER
GRN WIRE
HDLP SW PARK LP SIG
HEAD
HEADLAMP SWITCH
HEADUP DISPLAY SWITCH (IF EQUIPPED)
HORN SWITCH
HOT AT ALL TIMES
IGNITION MODE SWITCH
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT SIDE OF DASH)
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 1
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 2
LED BACK
LEFT STEERING WHEEL CONTROLS SWITCH
LIGHT CTRL SW REF
LIGHT CTRL SW SIG
LIGHT DIMMING CONTROL
LT GRN WIRE
OFF
OUTSIDE REARVIEW MIRROR SWITCH
PARK
PARK BRAKE CONTROL SWITCH (ON PARK BRAKE ASSEMBLY)
PASSENGER WINDOW SWITCH
PNK WIRE
RED/WHT WIRE
RIGHT STEERING WHEEL CONTROLS SWITCH
SERIAL DATA LOGIC
STEERING WHEEL)
SUNROOF SUNSHADE SWITCH
SUNROOF SWITCH
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> LIGHT CTRL SW REF
