Buick LaCrosse II (2009-2013) humidity sens sig twilight sentinel delay sig Wiring diagram

A/C COMPRESSOR SOLENOID VALVE AIR QUALITY SENSOR (BELOW AIR INLET GRILL PANEL) BLK WIRE BLK/DK BLU WIRE BLOWER MTR SPD CTRL BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COOLING FAN LOW SPEED RELAY DEFOGGER SYSTEM DK BLU WIRE DK BLU/LT GRN WIRE FUSE GRN WIRE GRN/YEL WIRE GRY WIRE GRY/DK BLU WIRE GRY/LT GRN WIRE HOT AT ALL TIMES HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED HOT W/ IGNITION MAIN RELAY ENERGIZED HUMIDITY SENS SIG TWILIGHT SENTINEL DELAY SIG HVAC CONTROL MODULE INSIDE AIR TEMP SENS LOW REF REAR DEFOG RLY CTRL LEFT COOLING FAN HIGH SPEED RELAY LINEAR INTERCONNECT NETWORK BUS 9 LOGIC LT GRN DK BLU/ WIRE LT GRN/VIO WIRE RED/VIO WIRE RED/WHT WIRE RIGHT COOLING FAN HIGH SPEED RELAY SOLAR SENS DRV SIG TEMP SENS LOW REF UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY) VIO/BLK WIRE VIO/GRY WIRE VIO/WHT WIRE WHT WIRE WHT/DK BLU WIRE YEL WIRE YEL/DK BLU WIRE YEL/RED WIRE
