Buick LaCrosse II (2009-2013) exterior rear compartment lid unlatch switch Wiring diagrams
This page contains all the electrical diagrams for the component. exterior rear compartment lid unlatch switch, in which he is found in the car Buick LaCrosse II (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram exterior rear compartment lid unlatch switch (1 of 2)
BLK WIRE
BLK/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP
DOME/ READING LAMPS
DRIVER SEAT ADJUSTER
DRIVER SEAT LUMBAR SUPPORT
DRIVER SEAT LUMBAR SUPPORT PUMP SWITCH
DRIVER SEAT LUMBAR SUPPORT VALVE ASSEMBLY SWITCH
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
FRONT DOME/ READING LAMPS
LEFT REAR SIDE MARKER LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT RIGHT LICENSE LICENSE LEFT PLATE PLATE BACKUP LAMP LAMP LAMP
LEFT SIDE OBJECT SENSOR
LEFT TAIL LAMP
LEFT TAIL/ STOP/ TURN SIGNAL LAMP
PARKING BRAKE CONTROL MODULE
PNK/WHT WIRE
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID LATCH
REAR PARKING ASSIST CONTROL MODULE
RIGHT LEFT SUNSHADE SUNSHADE MIRROR MIRROR LAMP LAMP
RIGHT SIDE OBJECT SENSOR
RUN WIRE
W/ LEFT HAND POWER LUMBAR SEAT
W/O LEFT HAND POWER LUMBAR SEAT
W/O REAR PARKING ASSIST
Go to component -> Ground distribution circuit (4 of 4) -> EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
Wiring diagram exterior rear compartment lid unlatch switch (2 of 2)
AJAR SW SIG 1
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (BCM) (LEFT SIDE OF DASH)
BRN/DK BLU WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/YEL WIRE
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
FUSE
FUSE OF DASH)
GRY WIRE
GRY/YEL WIRE
HANDLE SW OPEN SIG
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT SIDE
MTR RELEASE CTRL
PPL/WHT WIRE
REAR COMPARTMENT LID LATCH (IN TRUNK LID)
REAR COMPARTMENT LID UNLATCH RELAY
RED/WHT WIRE
SERIAL DATA
VIO/GRY WIRE
WHT WIRE
YEL WIRE
Go to component -> Trunk release circuit -> EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
