Buick LaCrosse II (2009-2013) driver seat seat adjuster memory switch control module Wiring diagram
This page shows the only wiring diagram for the component.driver seat seat adjuster memory switch control module, which is found in the car Buick LaCrosse II (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat seat adjuster memory switch control module (1 of 1)
ACCESSORY DC/AC POWER INVERTER MODULE
ACCESSORY POWER RECEPTACLE
ACCESSORY RELAY
B+ GND
BLK WIRE
BLOWER MOTOR CONTROL MODULE
BODY CONTROL MODULE
BRN/DK BLU WIRE
CENTER CONTROL 1 ACCESSORY POWER RECEPTACLE
CENTER CONTROL 2 ACCESSORY POWER RECEPTACLE
CIRCUIT BREAKER
DK BLU/WHT WIRE
DK GRN/WHT WIRE
DRIVER SEAT SEAT ADJUSTER MEMORY SWITCH CONTROL MODULE
FROM
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 5)
FROM INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 2 OF 5)
FUSE
FUSE (DIAGRAM 2 OF 5)
GND 120 VAC
GRY WIRE
GRY/GRN WIRE
GRY/VIO WIRE
INSTRUMENT PANEL FUSE BLOCK (LOWER LEFT SIDE OF DASH)
INVERTER CTRL
PASSENGER SEAT ADJUSTER SWITCH
RADIO
REAR COMPARTMENT LID RELEASE RELAY
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/DK BLU WIRE
RED/DK GRN WIRE
RED/LT GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
TAN WIRE
TAN/VIO WIRE
TELEMATICS COMMUNICATIONS INTERFACE CONTROL MODULE (W/ ONSTAR)
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
VIO WIRE
W/O W/ MEMORY MEMORY
Go to component -> Power distribution circuit (3 of 5) -> DRIVER SEAT SEAT ADJUSTER MEMORY SWITCH CONTROL MODULE
