Buick LaCrosse II (2009-2013) driver seat lumbar support pump switch Wiring diagram
This page shows the only wiring diagram for the component.driver seat lumbar support pump switch, which is found in the car Buick LaCrosse II (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat lumbar support pump switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP
DOME/ READING LAMPS
DRIVER SEAT ADJUSTER
DRIVER SEAT LUMBAR SUPPORT
DRIVER SEAT LUMBAR SUPPORT PUMP SWITCH
DRIVER SEAT LUMBAR SUPPORT VALVE ASSEMBLY SWITCH
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
FRONT DOME/ READING LAMPS
LEFT REAR SIDE MARKER LAMP
LEFT REAR TURN SIGNAL LAMP
LEFT RIGHT LICENSE LICENSE LEFT PLATE PLATE BACKUP LAMP LAMP LAMP
LEFT SIDE OBJECT SENSOR
LEFT TAIL LAMP
LEFT TAIL/ STOP/ TURN SIGNAL LAMP
PARKING BRAKE CONTROL MODULE
PNK/WHT WIRE
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID LATCH
REAR PARKING ASSIST CONTROL MODULE
RIGHT LEFT SUNSHADE SUNSHADE MIRROR MIRROR LAMP LAMP
RIGHT SIDE OBJECT SENSOR
RUN WIRE
W/ LEFT HAND POWER LUMBAR SEAT
W/O LEFT HAND POWER LUMBAR SEAT
W/O REAR PARKING ASSIST
Go to component -> Ground distribution circuit (4 of 4) -> DRIVER SEAT LUMBAR SUPPORT PUMP SWITCH
