Buick LaCrosse II (2009-2013) 4 2 7531 5060 network bus 9 lo spd gmlan serial data Wiring diagram

4 2 7531 5060 NETWORK BUS 9 LO SPD GMLAN SERIAL DATA ACTUATOR TRANSMIT SIG BREAKOUT TO INLINE TO DRIVER SEAT HARNESS) GRN WIRE GRN/BLU WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/GRN WIRE GRY/RED WIRE HEAD-UP DISPLAY (IF EQUIPPED) HVAC CONTROL MODULE INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (BELOW CENTER CONSOLE) INFO DISPLAY MODULE INSTRUMENT CLUSTER KEYLESS ENTRY CONTROL MODULE LEFT SIDE OBJECT SENSOR (IF EQUIPPED) (BEHIND LEFT REAR WHEEL) LO SPD GMLAN SERIAL DATA LT GRN/WHT WIRE MULTIMEDIA PLAYER INTERFACE MODULE (W/ AUDIO INTERFACE) NCA WIRE NETWORK BUS 8 OUTSIDE REAR VIEW MIRROR SWITCH PASSENGER PRESENCE DETECTION MODULE (UNDER FRONT PASSENGER'S SEAT) PASSENGER WINDOW SWITCH PPL RADIO RADIO/HVAC CONTROLS REAR PARKING ASSIST CONTROL MODULE (W/ REAR PARKING ASSIST SENSOR INDICATOR) RIGHT SIDE OBJECT SENSOR (BEHIND RIGHT REAR WHEEL) SEAT HEATING CONTROL MODULE (UNDER FRONT CENTER OF DRIVER SEAT) SEAT MEMORY CONTROL MODULE (UNDER DRIVER'S SEAT) SPLICE PACK TELEMATICS COMMUNICATIONS INTERFACE CONTROL MODULE VIO WIRE W/ MEMORY W/ NAVIGATION W/O MEMORY W/O NAVIGATION YEL WIRE
