Buick LaCrosse II (2009-2013) 22 23 wakeup serial data hood ajar sw sig Wiring diagram
This page shows the only wiring diagram for the component.22 23 wakeup serial data hood ajar sw sig, which is found in the car Buick LaCrosse II (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 22 23 wakeup serial data hood ajar sw sig (1 of 1)
1 23 24 B+ HI SPD DATA - HI SPD DATA +
10 9 16 NETWORK BUS 3 NETWORK BUS 2 NETWORK BUS 1
22 21 LO SPD DATA NETWORK BUS 4
22 23 WAKEUP SERIAL DATA HOOD AJAR SW SIG
24 25 HI SPD DATA + HI SPD DATA -
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN WIRE
COMPASS MODULE
DK BLU WIRE
DRIVER WINDOW MOTOR (DRIVER'S DOOR)
DRIVER WINDOW SWITCH
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/PPL WIRE
GRN/YEL WIRE
IMMOBILIZER CONTROL MODULE (CENTER CONSOLE)
INT N/W BUS 6
LEFT HEADLAMP
LEFT HEADLAMP HORIZONTAL MOTOR
LEFT REAR WINDOW SWITCH
LT BLU/VIO (GRN/PPL) WIRE
NETWORK BUS 1
NETWORK BUS 11
NETWORK BUS 2
NETWORK BUS 3
NETWORK BUS 4
PASSENGER WINDOW MOTOR (FRONT PASSENGER'S DOOR)
RED/WHT WIRE
RIGHT HEADLAMP
RIGHT HEADLAMP HORIZONTAL MOTOR
RIGHT REAR WINDOW SWITCH
SUNROOF CONTROL MODULE (IF EQUIPPED) (BEHIND ROOF CONSOLE)
SUNROOF SUNSHADE MOTOR MODULE (IF EQUIPPED) (REAR OF SUNROOF)
TRANSMISSION SHIFT LEVER POSITION INDICATOR
VIO/YEL WIRE
W/ COMPASS DISPLAY W/O ONSTAR
W/ KEYLESS ENGINE START SWITCH
WHT WIRE
WHT/DK BLU WIRE
Go to component -> Computer data lines circuit (2 of 3) -> 22 23 WAKEUP SERIAL DATA HOOD AJAR SW SIG
