Buick LaCrosse II (2009-2013) 10 13 20 25 wiper sw lo ref wiper sw lo sig wiper sw hi sig washer sw sig Wiring diagram
This page shows the only wiring diagram for the component.10 13 20 25 wiper sw lo ref wiper sw lo sig wiper sw hi sig washer sw sig, which is found in the car Buick LaCrosse II (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 10 13 20 25 wiper sw lo ref wiper sw lo sig wiper sw hi sig washer sw sig (1 of 1)
10 13 20 25 WIPER SW LO REF WIPER SW LO SIG WIPER SW HI SIG WASHER SW SIG
17 16 14 LAMP SPLY VOLT COIL SPLY VOLT WASHER RLY CTRL
23 24 SERIAL DATA (-) SERIAL DATA (+)
2501 2500 COMPUTER DATA LINES SYSTEM
BATT POSITIVE VOLT
BATTERY FUSE BLOCK (TOP OF
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN/GRY WIRE
BRN/LT GRN WIRE
COMPUTER DATA LINES SYSTEM
DELAY SWITCH
DK BLU WIRE
FUSE
FUSE (LOWER LEFT SIDE OF DASH)
FUSE BATTERY)
GRN WIRE
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT STRUT TOWER)
LO SPD GMLAN SERIAL DATA
LO WASHER FLUID IND CTRL
LOGIC INSTRUMENT CLUSTER
MIST
OFF
RED WIRE
RED/WHT WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF BATTERY)
VIO WIRE
WASHER SWITCH
WHT WIRE
WHT/VIO WIRE
WINDSHIELD WASHER FLUID LEVEL IND
WINDSHIELD WASHER FLUID LEVEL SWITCH (IN WASHER FLUID RESERVOIR)
WINDSHIELD WASHER PUMP (IN WASHER FLUID RESERVOIR)
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SPEED CONTROL RELAY
WINDSHIELD WIPER/WASHER SWITCH
WIPER SW HI SIG
WIPER SWITCH
WSW FUSE 56
YEL WIRE
YEL/BRN WIRE
Go to component -> Wiper/washer circuit -> 10 13 20 25 WIPER SW LO REF WIPER SW LO SIG WIPER SW HI SIG WASHER SW SIG
