3.6l vin 7, compressor circuit for Buick LaCrosse I (2004-2009)

9 39 25 48 49 A/C PRESS SIGNAL A/C CLU DIODE A/C CLUTCH FUSE 13 A/C COMP RELAY 38 A/C COMPRESSOR CLUTCH SOLENOID A/C COMPRESSOR TEMPERATURE SWITCH A/C REFRIGERANT PRESSURE SENSOR (ON LEFT SIDE OF ENGINE COMPT, ON ACCUMULATOR) A/C REQUEST IND A/C REQUEST SWITCH BATTERY IGN 1 VOLT CLASS 2 SERIAL BLK WIRE BLK/WHT WIRE COMPUTER DATA LINES SYSTEM DISPLAY FUSE 18 DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROL MODULE (ECM) (TOP OF ENGINE) ENGINE CONTROLS SYSTEM GROUND GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START HVAC CONTROL MODULE (CENTER OF DASH) HVAC FUSE I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) LOGIC LOW REF CLASS 2 SERIAL A/C COMP CLUTCH NCA WIRE ORG/ WIRE PNK WIRE RED/BLK WIRE UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER) WHT WIRE
