Buick LaCrosse I (2004-2009) w/o w/ power power seats seats wiring diagram
This page shows the only wiring diagram for the component.w/o w/ power power seats seats, which is found in the car Buick LaCrosse I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/o w/ power power seats seats wiring diagram (1 of 1)
3.6L
A/T SHIFT LOCK CONTROL PRNDL SOLENOID LAMP
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
DRIVER BACK DRIVER HEATED HEATED SEAT SEAT ELEMENT RELAY
DRIVER DOOR LOCK
DRIVER DRIVER SEAT SEAT BELT ADJUSTER SWITCH SWITCH
ELECTRONIC RIGHT COMPASS LICENSE MODULE LAMP
HORN SWITCH
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LEFT BODY REAR CONTROL DOOR MODULE LOCK (BCM)
LEFT REAR MARKER LAMP
LEFT UPPER TAIL/STOP LEFT, TURN TAIL SIGNAL LAMP LAMP
LOWER LEFT LEFT TAIL BACKUP LAMP LAMP
NCA WIRE
OUTSIDE DRIVER DOOR DRIVER REARVIEW LOCK WINDOW MIRROR SWITCH SWITCH SWITCH
PASSENGER BACK PASSENGER HEATED HEAT SEAT SEAT ELEMENT RELAY
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT BELT SWITCH
REAR OBJECT SENSOR CONTROL MODULE
REAR WINDOW DEFOGGER GRID
W/ CONSOLE SHIFT
W/ HEATED SEATS
W/ PARK ASSIST
W/ POWER SEATS
W/O POWER SEATS
W/O W/ POWER POWER SEATS SEATS
WHT WIRE
Go to component -> Ground distribution circuit (2 of 3) -> W/O W/ POWER POWER SEATS SEATS
