Buick LaCrosse I (2004-2009) w/ inside rearview mirror Wiring diagram
This page shows the only wiring diagram for the component.w/ inside rearview mirror, which is found in the car Buick LaCrosse I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ inside rearview mirror (1 of 1)
ACCESSORY VOLTAGE
BLK WIRE
BRN WIRE
CLOSE OPEN/VENT
DK BLU WIRE
HOT W/ RAP RELAY ENERGIZED
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH)
ORG/ WIRE
S/ROOF FUSE
SUNROOF MOTOR
SUNROOF SWITCH
SUNROOF SWITCH CLOSE SIGNAL GROUND
SUNROOF SWITCH LOW REFERENCE
SUNROOF SWITCH OPEN SIGNAL
W/ INSIDE REARVIEW MIRROR
YEL WIRE
Go to component -> Power top/sunroof circuit -> W/ INSIDE REARVIEW MIRROR
