Buick LaCrosse I (2004-2009) sdm class 2 serial data left seat belt sw right seat belt sw Wiring diagram
This page shows the only wiring diagram for the component.sdm class 2 serial data left seat belt sw right seat belt sw, which is found in the car Buick LaCrosse I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sdm class 2 serial data left seat belt sw right seat belt sw (1 of 1)
ABS/TCS CLASS 2 SERIAL DATA
ANTENNA SIGNAL
BLK WIRE
BLK/WHT WIRE
CHECK TIRE PRESSURE INDICATOR
CHECK TIRE PRESSURE SERVICE TIRE MONITOR
CLASS 2 SERIAL DATA
DK BLU WIRE
DOOR LOCK AJAR INDICATOR SWITCH
DRIVER SEAT BELT SWITCH (IN SEAT BELT BUCKLE)
FRONT AJAR PASSENGER DOOR LOCK (IN REAR SIDE OF FRONT PASSENGER'S DOOR)
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH)
IGN
INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) (UNDER RIGHT FRONT SEAT)
INSTRUMENT PANEL CLUSTER (IPC)
IPC CLASS 2 SERIAL DATA
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
MESSAGE REQUEST
NCA WIRE
ORG/ WIRE
PASSENGER SEAT BELT SWITCH (IN SEAT BELT BUCKLE)
PNK RFA CLASS 2 SERIAL DATA WIRE
PNK WIRE
PPL
PPL PASS SEAT BELT IND
RADIO
RED WIRE
RIGHT
SDM CLASS 2 SERIAL DATA
SDM CLASS 2 SERIAL DATA LEFT SEAT BELT SW RIGHT SEAT BELT SW
SEAT BELT INDICATOR
SIR FUSE 9
SOLID STATE
UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER)
WHT WIRE
YEL WIRE
Go to component -> Warning systems circuit (2 of 2) -> SDM CLASS 2 SERIAL DATA LEFT SEAT BELT SW RIGHT SEAT BELT SW
