Buick LaCrosse I (2004-2009) pwr seat circuit breaker Wiring diagrams
This page contains all the electrical diagrams for the component. pwr seat circuit breaker, in which he is found in the car Buick LaCrosse I (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
pwr seat circuit breaker wiring diagram (1 of 3)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER REAR VERTICAL MOTOR MOTOR ASSEMBLY (UNDER DRIVER SEAT)
DRIVER SEAT ADJUSTER SWITCH
FORWARD/
FRONT DOWN FRONT UP
FRONT VERTICAL MOTOR
HORIZONTAL MOTOR
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PWR SEAT CIRCUIT BREAKER
REAR DOWN
REAR UP
REAR- WARD
TAN WIRE
YEL WIRE
Go to component -> Driver power seat circuit -> PWR SEAT CIRCUIT BREAKER
pwr seat circuit breaker wiring diagram (2 of 3)
Go to component -> Driver"s lumbar circuit -> PWR SEAT CIRCUIT BREAKER
pwr seat circuit breaker wiring diagram (3 of 3)
3.8L 3.6L
ABS MTR FUSE 31
ABS SOL FUSE 19
AIR PUMP FUSE 25
AUTOMATIC A/C MANUAL A/C
BATT MAIN 1 FUSE 26
BATT MAIN 2 FUSE 27
BATT MAIN 3 FUSE 28
BATT MAIN 4 FUSE 30
BATTERY
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR CONTROL PROCESSOR
BODY CONTROL MODULE (BCM)
CANISTER FUSE PRK/ SWITCH FUSE
CHMSL/ BKUP FUSE INT ILLUM FUSE CLSTR FUSE
DATA LINK CONNECTOR (DLC)
DIGITAL RADIO RECEIVER
DR/LCK TRUNK FUSE RAP RELAY
DRIVER DRIVER SEAT SEAT ADJUSTER LUMBAR SWITCH SWITCH
DRIVER PASSENGER HEATED HEATED SEAT RELAY SEAT RELAY (IF EQUIPPED) (IF EQUIPPED)
DRIVER WINDOW SWITCH
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (W/ ABS)
EVAPORATIVE PARK EMISSION SWITCH (EVAP) CANISTER VENT SOLENOID
FRONT PASSENGER WINDOW SWITCH
FUSIBLE LINK (8 GA-
GENERATOR
HAZRD FUSE
HTD SEAT FUSE
HVAC CONTROL MODULE
HVAC FUSE
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH)
INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) MODULE
INSIDE SUNROOF REARVIEW MOTOR MIRROR
NCA WIRE
ONSTAR/ ALDL FUSE
ORG/ WIRE
OUTSIDE REAR VIEW MIRROR SWITCH
PASSENGER SEAT ADJUSTER SWITCH (IF EQUIPPED)
PCM/ ETC FUSE 16
POWERTRAIN ENGINE CONTROL CONTROL MODULE MODULE (PCM) (ECM)
PRK LAMP RELAY
PRK/LAMP FUSE
PWR SEAT CIRCUIT BREAKER
PWR WNDW CIRCUIT BREAKER
PWR/ MIR FUSE
R/ DEFOG RELAY
RADIO AUDIO AMPLIFIER (W/ 9 SPEAKER SYSTEM)
RDO AMP FUSE
RED WIRE
RFA/ MOD FUSE
S/ROOF FUSE
SECONDARY AIR INJECTION (AIR) PUMP RELAY (W/ CALIFORNIA PZEV EMISSION SYSTEM)
STARTER
TO TCM FUSE 8
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) (IF EQUIPPED)
W/ DIGITAL AUDIO SYSTEM
W/ DRIVER POWER LUMBAR CONTROL SEAT
W/ SUNROOF
W/ VEHICLE COMMUNICATION SYSTEM
W/O DIGITAL AUDIO SYSTEM
W/O DRIVER POWER LUMBAR CONTROL SEAT
W/O SUNROOF
WASHER/ RVC FUSE 6
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> PWR SEAT CIRCUIT BREAKER
