Buick LaCrosse I (2004-2009) (in forward lamp harness, approximately 19 cm from left front Wiring diagram
This page shows the only wiring diagram for the component.(in forward lamp harness, approximately 19 cm from left front, which is found in the car Buick LaCrosse I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in forward lamp harness, approximately 19 cm from left front (1 of 1)
3.6L
3.8L
A/C CLU DIODE
A/C COMPRESSOR CLUTCH
A/C WIPER RELAY 37 RELAY 45
AUTOMATIC TRANSMISSION TRANSMISSION CLUTCH INTERNAL MODE DIODE SWITCH (IMS)
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM)
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
EXCEPT SULEV
FUEL PP RELAY 41
HEADLAMP ASSEMBLY)
HOOD AJAR SWITCH
HORN ASSEMBLY
IGN 1 HDM BEAM MODULE 35
IGN 1 HDM BEAM RELAY 37 MODULE 35
LAMP
LEFT FRONT MARKER LAMP
LEFT HIGH BEAM HEADLAMP
POWERTRAIN CONTROL MODULE (PCM)
RIGHT COOLING FAN
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/ RIGHT TURN FRONT SIGNAL FOG LAMP LAMP
RIGHT HIGH BEAM HEADLAMP
SECONDARY AIR INJECTION (AIR) PUMP (SULEV)
SULEV
TAN WIRE
THROTTLE ACTUATOR CONTROL (TAC) MODULE
TRANSMISSION CONTROL MODULE (TCM) FUEL PP RELAY 41
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER FLUID PUMP
Go to component -> Ground distribution circuit (1 of 3) -> (IN FORWARD LAMP HARNESS, APPROXIMATELY 19 CM FROM LEFT FRONT
