Buick LaCrosse I (2004-2009) fog lp relay 36 Wiring diagram

3.6L 3.8L AMBIENT SUNLOAD LIGHT SENSOR SENSOR ASSEMBLY (TOP OF (TOP CENTER OF DASH) DASH) AUTO PARK BCM BCM CLASS 2 SERIAL BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN) BRN WIRE CLSTR FUSE COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE DRL AMBIENT LIGHT EXTERIOR LAMPS OFF FLASH TO PASS SW FOG FOG LAMP IND FOG LAMP RELAY CTRL FOG LP RELAY 36 FOG LPS FUSE 7 FRONT FOG LAMP SW FTP GRY WIRE HDLP SUGGEST IND HDM BEAM MODULE 35 HEAD HEADLAMP MOD CTRL HEADLAMP ON SIG HI BEAM RELAY 34 HI BEAM RLY CTRL HIGH BEAM IND HOT AT ALL TIMES I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) IGN IGN B+ INSTRUMENT PANEL CLUSTER (IPC) LAMP SWITCH ASSEMBLY LEFT FRONT FOG LAMP LEFT HIGH BEAM HEADLAMP LEFT LOW BEAM HEADLAMP LF HI BEAM FUSE 1 LF LO BEAM FUSE 3 LOGIC LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MANUAL AUTO A/C A/C OFF ORG/ WIRE PNK WIRE PNK/WHT WIRE PPL PPL HEADLAMP DIMMER SW RF HI BEAM FUSE 2 RF LO BEAM FUSE 4 RIGHT FRONT FOG LAMP RIGHT HEADLAMP ON FRAME) RIGHT HIGH BEAM HEADLAMP RIGHT LOW BEAM HEADLAMP SERIAL DATA TAN WIRE TURN SIGNAL/ MULTIFUNCTION SWITCH UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER) WHT WIRE YEL WIRE
