Buick LaCrosse I (2004-2009) drv dr lk sw unlock sig Wiring diagram
This page shows the only wiring diagram for the component.drv dr lk sw unlock sig, which is found in the car Buick LaCrosse I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv dr lk sw unlock sig (1 of 1)
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
CLASS 2 SERIAL
CLASS 2 SERIAL DATA
CLSTR FUSE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DOOR LOCKS SYSTEM
DRV DR LK SW UNLOCK SIG
GROUND
GRY WIRE
HAZRD FUSE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH)
INSTRUMENT PANEL CLUSTER (IPC)
LID AJAR SWITCH
LOGIC
LT BLU WIRE
LT GRN WIRE
MESSAGE CENTER
ORG/ WIRE
ORG/BLK WIRE
PAS DR LK SW UNLK SIG
PNK WIRE
REAR COMPARTMENT LID LATCH (IN REAR COMPT LID)
RED/BLK WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
TRUNK AJAR IND
TRUNK OPEN
TRUNK RELEASE CONTROL
Go to component -> Trunk release circuit -> DRV DR LK SW UNLOCK SIG
