Buick LaCrosse I (2004-2009) cellular micro phone signal Wiring diagram
This page shows the only wiring diagram for the component.cellular micro phone signal, which is found in the car Buick LaCrosse I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cellular micro phone signal (1 of 1)
AMBIENT LIGHT SENSOR IND
BACKUP LAMP SUPPLY VOLT
BACKUP LAMP SUPPLY VOLTAGE
BLK WIRE
BODY CONTROL MODULE (BCM) (BELOW LEFT SIDE OF DASH, LEFT OF STEERING COLUMN)
BRN/WHT WIRE
BUTTON BACK LIGHTING
CELLULAR MICRO PHONE SIGNAL
DK GRN/WHT WIRE
DRAIN WIRE
EMERGENCY IND
EMERGENCY SWITCH
GROUND
GRY WIRE
HEADLIGHT SENSOR IND
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH)
INSIDE REARVIEW MIRROR
KEYPAD
KEYPAD GREEN LED IND
KEYPAD GREEN LED SIGNAL
KEYPAD RED WIRE
KEYPAD SIGNAL
KEYPAD SUPPLY VOLTAGE
LED SIGNAL
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
MAX
MICRO PHONE
NCA WIRE
OFF MIN LOW HIGH
ONSTAR IND
ONSTAR KEYPAD
ONSTAR SWITCH
ORG/ WIRE
PHONE IND
PHONE SWITCH
POWER TOPS SYSTEM
RED LED IND WIRE
S/ROOF FUSE
SPLICE PACK
W/ SUNROOF
YEL WIRE
YEL/BLK WIRE
