Buick LaCrosse I (2004-2009) 48 15 5 37 ecm class 2 ser data req torque sig eng speed sig del torque sig Wiring diagram
This page shows the only wiring diagram for the component.48 15 5 37 ecm class 2 ser data req torque sig eng speed sig del torque sig, which is found in the car Buick LaCrosse I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 48 15 5 37 ecm class 2 ser data req torque sig eng speed sig del torque sig (1 of 1)
15 21 PCM CLASS 2 SER DATA ENG SPEED SIG
3.6L
3.6L W/ ACTIVE BRAKE CONTROL
3.8L
48 15 5 37 ECM CLASS 2 SER DATA REQ TORQUE SIG ENG SPEED SIG DEL TORQUE SIG
ABS FUSE 23
ABS MTR FUSE 31
ABS SOL FUSE 19
B+ MOTOR CONTROL
B+ SOL VALVE CONTROL
BLK WIRE
BLK/WHT WIRE
BRAKE PRESSURE MODULATOR VALVE (BPMV)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
ENG SPEED SIG (3.8L) HI SPD GMLAN SER DATA - (3.6L)
ENGINE CONTROL MODULE (3.6L) (TOP OF ENGINE)
ENGINE CONTROLS SYSTEM
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT W/ IGN 1 RELAY ENERGIZED
HSV 2 (W/ TCS)
LEFT FRONT INLET
LEFT FRONT OUTLET
LEFT REAR OUTLET
LT BLU WIRE
MAGNASTEER ACTUATOR (ON STEERING RACK ASSEMBLY)
ORG/ WIRE
ORG/BLK WIRE
PNK PNK WIRE
PNK WIRE
PUMP MOTOR
RED WIRE
RIGHT FRONT INLET
RIGHT LEFT FRONT REAR INLET OUTLET
RIGHT REAR INLET
RIGHT USV 1 (W/ TCS) REAR (W/ TCS) OUTLET
SOLENOID VALVES
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER)
USV 2 (W/ TCS)
W/ ACTIVE BRAKE CONTROL
W/ TRACTION CONTROL
W/O ACTIVE BRAKE CONTROL
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> 48 15 5 37 ECM CLASS 2 SER DATA REQ TORQUE SIG ENG SPEED SIG DEL TORQUE SIG
