Buick LaCrosse I (2004-2009) 12 volt reference ignition 3 voltage Wiring diagram

1-2 SHIFT SOLENOID VALVE 12 VOLT REFERENCE IGNITION 3 VOLTAGE 2-3 SHIFT SOLENOID VALVE 3.6L 3.6L 3.8L 3.8L A/C CLUTCH FUSE 13 A/C COMP RELAY 38 ABS FUSE 23 AUTOMATIC A/C PNK PNK WIRE AUTOMATIC TRANSMISSION AUX PWR FUSE 10 AUXILIARY POWER OUTLET BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE BODY CONTROL MODULE (BCM) BRN WIRE CIGAR LIGHTER CRANK RELAY 48 CRANK VOLTAGE CRUISE FUSE ENGINE CONTROL MODULE (ECM) ENGINE POWERTRAIN CONTROL CONTROL MODULE MODULE (ECM) (PCM) FROM IGN 1 RELAY (DIAGRAM 2 OF 4) FROM WASHER/RVC FUSE 6 (DIAGRAM 1 OF 4) HVAC CONTROL MODULE AUTOMATIC A/C MANUAL A/C I/P FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) IGN 1 RELAY 37 IGNITION 1 VOLTAGE IGNITION SWITCH INFLATABLE ELECTRONIC RESTRAINT COMPASS SENSING, MODULE DIAGNOSTIC MODULE INFLATABLE RESTRAINT PASSENGER AIR BAG ON/OFF INDICATOR INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSIDE AIR TEMPERATURE SENSOR KEY IN IGNITION SWITCH SIGNAL KEY-IN IGNITION SWITCH LOCK LT GRN WIRE NCA WIRE ORG/ WIRE P/TRAIN RELAY 40 PCM FUSE 15 PNK PNK PNK W/ PARK ASSIST WIRE PNK PNK WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) RED WIRE RUN WIRE SIR FUSE 9 DISPLAY FUSE 18 STEERING ANGLE SENSOR (W/ ABS) TCM FUSE 8 TO A/C CLUTCH FUSE (DIAGRAM 2 OF 4) TO ETC FUSE 17 (DIAGRAM 3 OF 4) TO FAN 2 FUSE (DIAGRAM 3 OF 4) TORQUE CONVERTER POWERTRAIN CLUTCH CONTROL (TCC) MODULE SOLENOID (PCM) VALVE TRANS SOL FUSE 21 TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION CONTROL MODULE (TCM) (3.6L) UNDERHOOD FUSE BLOCK (MOUNTED TO RIGHT STRUT TOWER) WHT WIRE YEL WIRE
