Blind spot monitoring circuit for Buick Envista I (2022-2024)
Blind spot monitoring circuit
BATT POS VOLT
BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SIDE OBJECT DETECTION INDICATOR
GRN WIRE
GROUND
GRY WIRE
GRY/YEL WIRE
HIGH SPEED GMLAN SERIAL DATA (+) 5
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
INSTRUMENT PANEL FUSE BLOCK
LEFT SIDE OBJECT DETECTION LED CTRL
LEFT SIDE OBJECT SENSOR MODULE (BEHIND LEFT CORNER OF REAR FASCIA)
LOW SPEED GMLAN SERIAL DATA
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
PASSENGER SIDE OBJECT DETECTION INDICATOR
RED/GRN WIRE
RIGHT SIDE OBJECT DETECTION LED CTRL
RIGHT SIDE OBJECT SENSOR MODULE (BEHIND RIGHT CORNER OF REAR FASCIA)
