Buick Envista I (2022-2024) w/o power lift gate Wiring diagram
This page shows the only wiring diagram for the component.w/o power lift gate, which is found in the car Buick Envista I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o power lift gate (1 of 1)
BACKUP LAMPS CIRCUIT
BLK WIRE
BRN/BLU WIRE
BRN/GRY WIRE
CENTER HIGH MOUNTED STOP LAMP
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND DISTRIBUTION SYSTEM
GRY/BRN WIRE
HANDLE SWITCH
LEFT BACKUP LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT LIFTGATE TAIL LAMP ASSEMBLY LEFT TAIL/STOP LAMP
LEFT OUTER TAIL LAMP
LEFT PARK/DAYTIME RUNNING LAMP
LEFT REAR SIDE MARKER LAMP
LEFT TAIL LAMP ASSEMBLY
LIFTGATE CONTROL MODULE
LOGIC
LOW SPEED GMLAN
MULTI-FUNCTION CARRIER LICENSE PLATE LAMP
NCA WIRE
OPEN SIGNAL
PASSENGER OUTSIDE REAR VIEW MIRROR
REAR CLOSURE
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT LIFTGATE TAIL LAMP ASSEMBLY
RIGHT TURN SIGNAL REPEATER LAMP
SERIAL DATA
VIO/GRY WIRE
VIO/WHT WIRE
W/ POWER LIFT GATE
W/O POWER LIFT GATE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component: -> Exterior lamps circuit (3 of 3) -> W/O POWER LIFT GATE
