Buick Envista I (2022-2024) transmission fluid pressure switch Wiring diagram
This page shows the only wiring diagram for the component.transmission fluid pressure switch, which is found in the car Buick Envista I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission fluid pressure switch (1 of 1)
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ENGINE CONTROL MODULE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
HIGH SPEED GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED
HOT W/ IGNITION MAIN RELAY ENERGIZED
PRESSURE CONTROL SOLENOID VALVE 1
PRESSURE CONTROL SOLENOID VALVE 2
PRESSURE CONTROL SOLENOID VALVE 3
PRESSURE CONTROL SOLENOID VALVE 4
PRESSURE CONTROL SOLENOID VALVE 5
RED/YEL WIRE
SHIFT SOLENOID VALVE 1
SOL VALVE LOW SIDE CTRL
TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID VALVE
TRANS PARK/ NEUTRAL SIG 1
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID PRESSURE SWITCH
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SHAFT SPEED SENSOR
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
UNDERHOOD FUSE BLOCK
VIO/BLU WIRE
VIO/GRY WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component: -> Transmission circuit (1 of 2) -> TRANSMISSION FLUID PRESSURE SWITCH
