Buick Envista I (2022-2024) sunroof tilt switch Wiring diagrams

This page contains all the electrical diagrams for the component. sunroof tilt switch, in which he is found in the car Buick Envista I (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram sunroof tilt switch (1 of 3)

Wiring diagram sunroof tilt switch for Buick Envista I (2022-2024)

Get access

2 WAY BLK WIRE BODY CONTROL MODULE DOME/ READING LAMPS DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR LOCK SWITCH DRIVER EXTERIOR DOOR HANDLE ASSEMBLY DRIVER EXTERIOR DOOR HANDLE SWITCH DRIVER OUTSIDE REAR- VIEW MIRROR DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT LUMBAR SUPPORT SWITCH DRIVER WINDOW SWITCH INSIDE REAR VIEW MIRROR INTERIOR LIFTGATE CONTROL INDICATOR LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR WINDOW SWITCH LEFT SUNSHADE MIRROR LAMP NCA WIRE PASSENGER AIR BAG DISABLED INDICATOR POWER SUPPLY TRANSFORMER RAIN/ AMBIENT LIGHT SENSOR MODULE RIGHT SUNSHADE MIRROR LAMP SUNROOF SWITCH SUNROOF TILT SWITCH TELEMATICS BUTTON ASSEMBLY TRANSMISSION SHIFT LEVER W/ ACTIVE SAFETY W/ AUTOMATIC LIFTGATE W/ MOISTURE SENSITIVE WINDSHIELD WIPER SYSTEM W/ REMOTE ENTRY W/ SUNROOF W/O MOISTURE SENSITIVE WINDSHIELD WIPER SYSTEM WHT WIRE WINDSHIELD FRONT VIEW CAMERA WINDSHIELD TEMPERATURE, INSIDE MOISTURE SENSOR

Go to component: -> Ground distribution circuit (5 of 5) -> SUNROOF TILT SWITCH

Wiring diagram sunroof tilt switch (2 of 3)

Wiring diagram sunroof tilt switch for Buick Envista I (2022-2024)

Get access

BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE CENTER CONSOLE REAR USB RECEPTACLE DRIVER DOOR LOCK SWITCH GRN/RED WIRE HEADLAMP SWITCH IGNITION MODE SWITCH INTERIOR LIFTGATE CONTROL SWITCH PARK BRAKE CONTROL SWITCH PASSENGER DOOR LOCK SWITCH SUNROOF SWITCH SUNROOF TILT SWITCH USB RECEPTACLE YEL WIRE YEL/GRY WIRE

Go to component: -> Instrument illumination circuit (2 of 2) -> SUNROOF TILT SWITCH

Wiring diagram sunroof tilt switch (3 of 3)

Wiring diagram sunroof tilt switch for Buick Envista I (2022-2024)

Get access

BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLU/VIO WIRE CLOSE COMPUTER DATA LINES SYSTEM GRN/BRN WIRE HOT AT ALL TIMES ILL INSTRUMENT PANEL FUSE BLOCK RED/BLU WIRE SUNROOF MOTOR SUNROOF SWITCH SUNROOF TILT SWITCH WHT/GRN WIRE YEL WIRE

Go to component: -> Power top/sunroof circuit -> SUNROOF TILT SWITCH
