Buick Envista I (2022-2024) serial data 2 Wiring diagrams

ACTIVE GRILLE AIR SHUTTER 1 ACTUATOR BLK WIRE BLU/BRN WIRE COMPUTER DATA LINES SYSTEM DISPLAY SIGNAL (-) DRIVER INFORMATION CENTER DISPLAY ENGINE CONTROL MODULE ENGINE CONTROL MODULE LIN BUS 1 GRN/VIO WIRE GRY/GRN WIRE HIGH SPEED GMLAN SERIAL DATA (+) 7 HOT W/ ENGINE CONTROLS IGNITION RELAY ENERGIZED INFOTAINMENT INSTRUMENT CLUSTER LOGIC LOW SPEED GMLAN LVDS LVDS BK RADIO RADIO CONTROLS SERIAL DATA 2 UNDERHOOD FUSE BLOCK VIO/BLU WIRE WHT WIRE

ABS IND. ACCESSORY WAKE UP SERIAL DATA BATTERY POSITIVE VOLTAGE BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/VIO WIRE BLU/YEL WIRE BODY CONTROL MODULE (BELOW CENTER OF DASH) BRAKE APPLY SENSOR CONTROL BRAKE APPLY SENSOR LOW REFERENCE BRAKE APPLY SENSOR SIG BRAKE IND BRAKE PEDAL POSITION SENSOR BRAKE POSITION SENSOR SIG BRN WIRE COMPUTER DATA LINES SYSTEM DISPLAY SIGNAL (-) DRIVER INFORMATION CENTER DISPLAY ENGINE CONTROL MODULE ENGINE CONTROL SENSORS 5 VOLT REFERENCE 1 ENGINE CONTROL SENSORS LOW REFERENCE 1 ESC IND ESC OFF IND GRY/GRN WIRE GRY/RED WIRE HIGH SPEED GMLAN SERIAL DATA (+) 7 HOT AT ALL TIMES INFOTAINMENT INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK LOGIC LOW SPEED GMLAN LVDS LVDS BK PARK BRAKE CONTROL SWITCH PARKING BRAKE IND. RADIO RADIO CONTROLS RED/VIO WIRE SERIAL DATA 2 SERVICE PARKING BRAKE INDICATOR TRACTION CONTROL OFF IND VIO/YEL WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE CLUSTER CONTROL MODULE ETHERNET BUS 4 (-) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRY WIRE GRY/GRN WIRE GRY/WHT WIRE HI SPD GMLAN INFOTAINMENT DISPLAY SIG INSTRUMENT CLUSTER INSTRUMENT PANEL LEFT SIDE OBJECT SENSOR MODULE LIN BUS 1 LIN BUS 2 LO SPD GMLAN LOGIC LOW SPEED GMLAN LVDS RADIO RADIO CONTROLS RIGHT SIDE OBJECT SENSOR MODULE RIGHT STEERING WHEEL CONTROLS SWITCH SEAT HEATING CONTROL MODULE SERIAL DATA SERIAL DATA (-) 5 SERIAL DATA 2 STEERING WHEEL AIR BAG COIL TRANSMISSION SHIFT LEVER POSITION INDICATOR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/GRY WIRE

BLU WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/YEL WIRE COMM ENABLE COMMUNICATION ENABLE ETHERNET BUS 4 (-) GRN WIRE GRN/BLU WIRE GRY WIRE GRY/GRN WIRE GRY/WHT WIRE HI SPD GMLAN INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE LIFTGATE CONTROL MODULE LO SPD GMLAN PARKING ASSIST CONTROL MODULE SERIAL DATA SERIAL DATA (-) 9 SERIAL DATA 2 TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/GRY WIRE

ACCESSORY WAKE-UP BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/YEL WIRE COMMUNICATION ENABLE GRN WIRE HI SPD GMLAN SERIAL DATA SERIAL DATA (-) (1) SERIAL DATA 2 VIO/GRN WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/GRY WIRE WINDSHIELD FRONT VIEW CAMERA (TOP CENTER OF WINDSHIELD)

BATTERY FUSE BLOCK BATTERY POSITIVE VOLT BK LVDS INFOTAINMENT DISPLAY SIG BLK WIRE BLU WIRE BLU/YEL WIRE COMPUTER DATA LINES SYSTEM DISPLAY SIG + DRIVER INFORMATION CENTER DISPLAY GRY/GRN WIRE HIGH SPEED GMLAN SERIAL DATA (-) (1) HIGH SPEED GMLAN SERIAL DATA (-) (2) HOT AT ALL TIMES INFOTAINMENT INSTRUMENT CLUSTER LOGIC LOW SPEED GMLAN LVDS POWER STEERING CONTROL MODULE (LEFT OF STEERING COLUMN) RADIO RED/GRN WIRE SERIAL DATA 2 SERIAL DATA COMMUNICATION ENABLE WHT WIRE WHT/BLU WIRE

1-BK 1-VT 2-BK 2-VT AM/FM AUDIO (-) CTRL AUDIO SIG + BATT POS VOLT BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/YEL WIRE CELL CELL/GPS CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA CELLULAR TELEPHONE COAX COMPUTER DATA LINES SYSTEM DOWN GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HIGH SPEED GMLAN LEFT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE LOW REFERENCE LOW SPEED GMLAN LVDS MICROPHONE LO REF MICROPHONE SIG NCA WIRE RADIO ANTENNA RADIO PRESETS STEERING WHEEL CONTROLS SWITCH REAR RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE RED/BLU WIRE RIGHT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE SERIAL DATA (-) 9 SERIAL DATA 2 SIG GND VOICE RECOGNITION W/ S-BAND DIGITAL AUDIO SYSTEM W/O S-BAND DIGITAL AUDIO SYSTEM WHT/YEL WIRE WLAN WIRELESS COMMUNICATION ANTENNA XM RADIO ANTENNA YEL/BLU WIRE

1-BK 1-VT 2-BK 2-VT AM/FM AUDIO (-) CTRL AUDIO SIG + BATT POS VOLT BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/YEL WIRE CELL CELL/GPS CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA CELLULAR TELEPHONE COAX COMPUTER DATA LINES SYSTEM DOWN GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HIGH SPEED GMLAN LEFT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE LOW REFERENCE LOW SPEED GMLAN LVDS MICROPHONE LO REF MICROPHONE SIG NCA WIRE RADIO ANTENNA RADIO PRESETS STEERING WHEEL CONTROLS SWITCH REAR RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE RED/BLU WIRE RIGHT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE SERIAL DATA (-) 9 SERIAL DATA 2 SIG GND VOICE RECOGNITION W/ S-BAND DIGITAL AUDIO SYSTEM W/O S-BAND DIGITAL AUDIO SYSTEM WHT/YEL WIRE WLAN WIRELESS COMMUNICATION ANTENNA XM RADIO ANTENNA YEL/BLU WIRE

A/C REFRIGERANT PRESSURE SENSOR BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BRN/GRN WIRE BRN/WHT WIRE CHECK ENGINE COMPUTER DATA LINES SYSTEM DISPLAY SIG + ENGINE HOOD SWITCH ENGINE OIL PRESSURE SENSOR FUEL LEVEL SENSOR FUEL PUMP FUEL PUMP, LEVEL SENSOR ASSEMBLY (TOP LEFT SIDE OF FUEL TANK) FUEL TANK PRESSURE SENSOR GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRY WIRE GRY/GRN WIRE IND CTRL INFOTAINMENT LOW SPEED GMLAN LVDS NCA WIRE RADIO RED/WHT WIRE SERIAL DATA 2 VIO/BLU WIRE VIO/GRY WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE
