Buick Envista I (2022-2024) right front side impact sensor Wiring diagram
This page shows the only wiring diagram for the component.right front side impact sensor, which is found in the car Buick Envista I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front side impact sensor (1 of 1)
AIR BAG
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BRN/ORG WIRE
DRIVER SEAT BELT RETRACTOR PRETENSIONER
DRIVER SEAT BELT SWITCH DRIVER SEAT BELT BUCKLE
GRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
IND
INSTRUMENT PANEL FUSE BLOCK
LEFT FRONT IMPACT SENSOR
LEFT FRONT ROOF RAIL AIR BAG
LEFT FRONT SIDE IMPACT SENSOR
LEFT REAR SIDE IMPACT SENSOR
OFF IND
ON IND.
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/WHT WIRE
ORG/YEL WIRE
PASSENGER
PASSENGER AIR BAG DISABLED INDICATOR
PASSENGER SEAT BELT RETRACTOR PRETENSIONER
RED/BLU WIRE
RIGHT FRONT IMPACT SENSOR
RIGHT FRONT SIDE IMPACT SENSOR
RIGHT REAR SIDE IMPACT SENSOR
SEAT BELT 2
SHORTING BAR
VIO/ORG WIRE
VIO/WHT WIRE
WHT/ORG WIRE
Go to component: -> Supplemental restraints circuit (2 of 3) -> RIGHT FRONT SIDE IMPACT SENSOR
