Buick Envista I (2022-2024) replicated sig Wiring diagram
This page shows the only wiring diagram for the component.replicated sig, which is found in the car Buick Envista I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram replicated sig (1 of 1)
AUTOMATIC TRANSMISSION ACCUMULATOR SOLENOID VALVE
BLK/GRY WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BUS ENABLE
CAM POS ACTR VLV 1
CAM POS SENS 1
CHARGE INDICATOR CTRL
CRANK POS SENS SIG
CRANKCASE PRESSURE SENSOR
ENGINE CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
ENGINE CONTROLS IGNITION RELAY
EVAPORATIVE EMISSION VENT SOLENOID VALVE
GRN WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGNITION CTRL 2
INTAKE CAM POS SENS 1
KNOCK SENSOR
POS ACTR SOL VLV 1
RED/BLU WIRE
RED/WHT WIRE
REPLICATED SIG
SENS 1 VOLT REF
SOLENOID VALVE CTRL
SOUND SYSTEMS
STARTING/ CHARGING SYSTEM
UNDERHOOD FUSE BLOCK
VIO/BLK WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRY WIRE
YEL/VIO WIRE
