Buick Envista I (2022-2024) rain/ambient light sensor module Wiring diagrams

This page contains all the electrical diagrams for the component. rain/ambient light sensor module, in which he is found in the car Buick Envista I (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rain/ambient light sensor module (1 of 2)

Wiring diagram rain/ambient light sensor module for Buick Envista I (2022-2024)

Get access

ACCESSORY IGN VOLT ACCESSORY WAKEUP BLU WIRE BLU/GRY WIRE BLU/YEL WIRE BODY CONTROL MODULE BODY CONTROL MODULE (BELOW CENTER OF DASH) COMMUNICATION ENABLE CONTROL SOLENOID VALVE ASSEMBLY GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/YEL WIRE HI SPD GMLAN HIGH SPEED BUS TERMINATING RESISTOR IMMO LIN BUS 1 IMMOBILIZER CONTROL MODULE LEFT REAR WINDOW SWITCH LIN BUS 1 LIN BUS 2 LIN BUS 3 LIN BUS 4 LO SPD GMLAN RAIN/AMBIENT LIGHT SENSOR MODULE RIGHT REAR WINDOW SWITCH SERIAL DATA SERIAL DATA (-) (1) SUNROOF MOTOR VIO/YEL WIRE W/ WINDSHIELD WIPER, SLIDING SUNROOF W/O SLIDING SUNROOF W/O WINDSHIELD WIPER WHT WIRE WHT/BLU WIRE WHT/GRY WIRE

Go to component: -> Computer data lines circuit (5 of 7) -> RAIN/AMBIENT LIGHT SENSOR MODULE

Wiring diagram rain/ambient light sensor module (2 of 2)

Wiring diagram rain/ambient light sensor module for Buick Envista I (2022-2024)

Get access

B+ VOLT BLK WIRE BLK/WHT WIRE COMPUTER DATA LINES SYSTEM GMLAN GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRY/VIO WIRE HOT AT ALL TIMES HVAC CONTROL MODULE INSTRUMENT PANEL FUSE BLOCK LIN BUS 1 LIN BUS 2 LOW SPEED RAIN/AMBIENT LIGHT SENSOR MODULE RED/GRN WIRE SERIAL DATA SIG GND W/ MOISTURE SENSITIVE WINDSHIELD WIPER SYSTEM W/O MOISTURE SENSITIVE WINDSHIELD WIPER SYSTEM WINDSHIELD TEMPERATURE, INSIDE MOISTURE SENSOR WINDSHIELD WASHER PUMP

Go to component: -> Wiper/washer circuit (2 of 2) -> RAIN/AMBIENT LIGHT SENSOR MODULE
