Buick Envista I (2022-2024) park lock sol actuator ctrl Wiring diagram
This page shows the only wiring diagram for the component.park lock sol actuator ctrl, which is found in the car Buick Envista I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park lock sol actuator ctrl (1 of 1)
A/T OIL TEMP IND
ACCESSORY POWER CTRL
AUTOMATIC TRANSMISSION ACCUMULATOR SOLENOID VALVE
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BELOW CENTER OF DASH)
BODY CONTROL MODULE LIN BUS 2
COMPUTER DATA LINES SYSTEM
DISPLAY SIG +
DRIVER INFORMATION CENTER DISPLAY
GRN/BLK WIRE
GRN/BLU WIRE
HIGH SPEED GMLAN SERIAL DATA (-) (1)
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
KEY CAPTURE/COLUMN LOCK SHIFT POSI SIG
LIN BUS 1
LOGIC
LVDS
LVDS BK
NCA WIRE
PARK LOCK SOL ACTUATOR CTRL
PARK POSITION SWITCH
PRESS BRAKE
RADIO
RED/VIO WIRE
TAP UP/TAP DOWN SW SIG
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRY WIRE
WHT/VIO WIRE
Go to component: -> Transmission circuit (2 of 2) -> PARK LOCK SOL ACTUATOR CTRL
