Buick Envista I (2022-2024) med heat ind Wiring diagram

BATT POS VOLT BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BODY CTRL MODULE LIN BUS 2 BRN/BLK WIRE BRN/BLU WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER BACK SEAT HEATING ELEMENT DRIVER CUSHION SEAT HEATING ELEMENT DRIVER HEATED/BACK SWITCH DRV HEATED SEAT THERMISTOR LO REF DRV SEAT BACK HEATING TEMP SENS SIG DRV SEAT HEATING ELEMENT CTRL DRV SEAT HEATING ELEMENT LO REF DRV SEAT HEATING TEMP SENS SIG GRN WIRE GRN/BLU WIRE GRY/BLK WIRE HIGH HEAT IND HOT AT ALL TIMES HVAC CONTROL MODULE (CENTER OF DASH) LOGIC LOW HEAT IND LOW HEAT IND MED HEAT IND LOW SPEED GMLAN SERIAL DATA MED HEAT IND NCA WIRE PASS HEATED BACK THERMISTOR LO REF PASS HEATED SEAT THERMISTOR LO REF PASS SEAT BACK HEATING TEMP SENS SIG PASS SEAT HEATING ELEMENT CTRL PASS SEAT HEATING ELEMENT LO REF PASS SEAT HEATING TEMP SENS SIG PASSENGER BACK SEAT HEATING ELEMENT PASSENGER CUSHION SEAT HEATING ELEMENT PASSENGER HEATED/BACK SWITCH RED/BLU WIRE RED/GRN WIRE SEAT HEATING CONTROL MODULE (UNDER FRONT OF PASSENGER SEAT) UNDERHOOD FUSE BLOCK WHT/BLU WIRE WHT/GRY WIRE YEL/GRY WIRE
