Buick Envista I (2022-2024) lo spd gmlan serial ata Wiring diagram

BATT POS VOLT BATTERY FUSE BLOCK BK DISPLAY SIGNAL BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/VIO WIRE BRAKE FLUID LEVEL SIG BRAKE FLUID LEVEL SWITCH BRAKE IND BRAKE MASTER CYLINDER) BRAKE SYSTEM CONTROL MODULE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY DRIVER SEAT BELT BUCKLE DRIVER SEAT BELT SWITCH DRV SEAT BELT SW LO REF DRV SEAT BELT SW SIG ETHERNET BUS 4 (-) GRN WIRE GRN/GRY WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HIGH SPEED GMLAN SERIAL DATA (-) (1) HOT AT ALL TIMES INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE INSTRUMENT CLUSTER LO SPD GMLAN SERIAL ATA LOGIC LVDS ORG/BRN WIRE ORG/VIO WIRE PARK BRAKE APPLY SW SIG PARK BRAKE APPLY SW VOLT REF PARK BRAKE CONTROL SWITCH PARK BRAKE IND PARK BRAKE RELEASE SW SIG PARK BRAKE RELEASE SW VOLT REF PARK BRAKE SW SIG PARK BRAKE SW SUPPLY VOLT PARKING BRAKE SWITCH PASS SEAT BELT SW LO REF PASS SEAT BELT SW SIG PASSENGER SEAT BELT BUCKLE PASSENGER SEAT BELT SWITCH RADIO RED/GRY WIRE SEAT BELT IND WHT WIRE YEL WIRE YEL/RED WIRE
