Buick Envista I (2022-2024) interior lp ctrl Wiring diagram
This page shows the only wiring diagram for the component.interior lp ctrl, which is found in the car Buick Envista I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior lp ctrl (1 of 1)
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BODY CONTROL MODULE (BELOW CENTER OF DASH)
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
COURTESY LP SW SIG
DRIVER DOOR LATCH ASSEMBLY
DRIVER INFORMATION CENTER DISPLAY
DRIVER WINDOW SWITCH
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
IGNITION MODE SW ACC LED SIG
IGNITION MODE SW START LED SIG
IGNITION MODE SWITCH
INADVERTENT LOAD CTRL REAR COMPARTMENT COURTESY LP CTRL
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
INTERIOR LP CTRL
INTERIOR LP DEFEAT SW SIG
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR WINDOW SWITCH
LIN BUS 3
LIN BUS 4
LOGIC
LVDS BK
REAR COMPARTMENT COURTESY LAMP
RED/VIO WIRE
RED/WHT WIRE
WHT WIRE
WHT/BRN WIRE
Go to component: -> Courtesy lamps circuit (1 of 2) -> INTERIOR LP CTRL
